SZ-2000 Model Double Shaft Shredder with 640027003500 mm Size and 2000*1490 mm Feed Inlet for Industrial Metal Recycling

Product Categories

Henan Xrido Environmetal Protection Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

SZ-2000 Model Double Shaft Shredder with 640027003500 mm Size and 2000*1490 mm Feed Inlet for Industrial Metal Recycling

Place of Origin : Henan, China

Brand Name : HJ

MOQ : 1

Price : $5,280-7,250

Power : 90 kW

Weight : 20100 kg

Operating Mode : Automatic

Blades Material : 9CrSi/D2/SKD-11

Core Components : PLC, Engine, Bearing, Gearbox, Motor

Material Processed : Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum

Model SZ-2000 Size : 6400*2700*3500 mm

Feed Inlet Size : 2000*1490 mm

Blade Diameter : 600 mm

Blade Thickness : 50/75 mm

Power per Shaft : 90 kW

Spare Parts : 5 piece

Bearing Seal : Six-fold

Cutter Arrangement : Helix

Tool Repair : Coating and welding

Contact Now

SZ-2000 Model Double Shaft Shredder with 6400*2700*3500 mm Size and 2000*1490 mm Feed Inlet for Industrial Metal Recycling

The double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel, pallets, etc. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It is widely used in industry waste recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, papermaking industry and etc.

Technical parameters

model	size(LWH)(mm)	feed inlet size(mm)	blade diameter(mm)	blade thickness(mm)	power(kw)	weight(kg)
SZ-500	280013001850	500*480	200	20	11*2	2200
SZ-800	300013001850	800*480	200	20	15*2	2500
SZ-1000	330019002200	1000*690	300	40	22*2	5200
SZ-1200	360020002200	1200*690	330	40	30*2	6400
SZ-1500	418021002400	1500*690	550	50/75	55*2	9000
SZ-1800	580024003300	1800*1206	550	50/75	75*2	13600
SZ-2000	640027003500	2000*1490	600	50/75	90*2	20100
SZ-2500	750032003800	2500*1800	600	75/100	110*2	25000
SZ-3000	860035004000	3000*1800	600	75/100	160*2	31000

Remarks:

1. The number of blade claws, diameter and thickness can be customized according to the type of material and the size of the discharge;

2. The output of the equipment will be different due to different material types and discharge scales.

1.Metal: aluminum can bundle, steel drum, car shell, color steel tile, bicycle, copper aluminum radiator, oil filter, scrap wires,cables, aluminum composite plastic panel, steel wire rope, gas tank, iron scrap, zip-top can, engine case, paint bucket, etc.
2.Plastic: plastic pallet, plastic drum, plastic bucket, plastic film, waste appliances shell, garbage plastic drum, IBC drum, IBC barrel,garbage bag, rubbish bag, plastic pipe, washing machine, forklift pallet, lead acid battery shell, etc.
3.Textile: scrap clothes, shoes, fishing net, woven bag, ton bag, jumbo bag, fishing net bundles, dust collector bag, industrial textile waste, etc.
4.Wood: wood mattress, wood furniture, wood pallet, scrap timber, sawdust chipboard, composite board, wooden door, forklift pallet, wood board, wood template, wooden case, wooden box, wood sofa, wood bed, etc.
5.Paper: scrap paper and cartons, including scrap books, carton board, carton box, packaging box, waste newspaper, office paper,printing paper, paperboard, etc.
6.Waste household appliances: TV, washing machine, refrigerator shell etc.
7. Pipes: large pipes, pipe fittings, PE pipes etc.
8.Scrap tires: car tires, truck tires etc.
9.All kinds of Kitchen waste, domestic waste, rdf derivatives, medical waste,garden waste etc.

Our advantage：

1. It has the characteristics of low speed, high torque and low noise. It is controlled by PLC. It has the functions of starting,stopping, reversing and overloading automatic reversing.
2. The motor + reducer drives the cutter shaft to achieve the shearing effect of low speed and high torque.
3. Bearing six-fold seal, effective waterproof and dust-proof, prolong the service life of bearings.
4. After tool wear, the repair technology of tool coating and welding is adopted to realize the repeated use of the tool, which greatly reduces the maintenance cost of the tool.
5. Separate box design, can easily and quickly remove the entire axle (axle, blade, bearing, sealing system).
6. Tools are arranged according to helix to achieve high efficiency cutting.
7. Both the inner hole and the spindle face of the cutter are designed in hexagonal form to realize the uniformity of the force exerted on the cutter.
8. According to different materials and product shapes to be torn up, different types of cutters can be selected.

COMPANY PROFILE

Q: Do you accept Custom-made? A: Yes, we can custom the machine according to clients requirements.
Q: How can i get a suitable machine?
A: Tell us your requirements, such as raw material, out put size, capacity etc, our engineer can recommend the suitable configuration and provide quotation for you.
Q: How long is your delivery time ?
A: 1 set for normal machine needs about 5 working days, if 1 or more containers, needs about 20 working days.
Q: How long is the warranty?
A: 1 year since the date of shipment, if parts failure or damage(because of the quality problem, except wearing parts), our company will provide these parts for free.
Q:What is your payment term?
A: T/T 100% before shipment, L/C at sign, or Trade Assurance order recommended.
